- Years of Manufacture: 1980 - 1985
- Number Built: 60,231
- Price at Introduction:
- Utility: $6971
- Kingswood Utility: $7640
- Kingswood Panel Van: $7167
- One-Tonner: $6,940
- Statesman DeVille: $14,790
- Statesman Caprice: $19,769
- Models:
- Holden Utility
- Holden Panel Van
- Kingswood Utility
- Kingswood Panel Van
- One-Tonner
- Statesman DeVille
- Statesman Caprice
- Statesman DeVille Series II
- Statesman Caprice Series II
- HDT Magnum
- Date(s) of Introduction:
- Panel Van, Utility,
Kingswood Utility and One-Tonner:
20th April, 1980
- Statesmans: 22nd June, 1980
- Commercials (with revised grille): August,
1980
- Statesman Series II: August, 1983
- To Identify:
- Similar body to HZ with separate grille
and headlights
- Kingswood Utility with redesigned front
nose section with grille and headlights
- Early model WB's have circular headlights,
grey grille with three holes and grey
divider with Holden badge located above
the grille
- Kingswood and late model WB (from August
1980 onward) use rectangular headlights
and a black grate style grille and the
Holden badge now located in the centre
of the grille
- WB Statesman features slightly shorter
but taller body over HZ, and incorporates
a new "third" rear window
- Statesman DeVille has thick bar grill
with "DeVille" emblem located
on lower left corner
- Statesman Caprice has grille with thinner
bars to DeVille, making for a more elegant
and refined appearance, and featuring
integrated "Caprice" emblem
- Brock Statesman Magnum features Momo
aero-disc wheels, colour coded bumpers.
- Series II Statesmans have special decals
identifying them, and new badging
- Body:
- Unitary construction (Monocoque)
- Full Chassis (Commercials)
- Exterior Dimensions:
- Total Length:
- Utility: 4938mm
- Panel Van: 4945mm
- One-Tonner: 4897mm
- Statesman: 5157mm
- Total Width:
- Utility, Panel Van and One-Tonner:
1877mm
- Statesman: 1899mm
- Total Height at kerb weight:
- Utility: 1395mm
- Panel Van: 1603mm
- One-Tonner: 1420mm
- Statesman DeVille: 1370mm
- Statesman Caprice: 1390mm
- Wheelbase:
- Front Track:
- Commercials: 1520mm
- Statesman Caprice: 1531mm
- Statesman DeVille: 1523mm
- Rear Track:
- Commercials: 1530mm
- Statesman Caprice: 1540mm
- Statesman DeVille: 1536mm
- Kerb Weight:
- Utility: 1360kg
- Kingswood Utility (6 Cylinder): 1370kg
- Kingswood Utility (8 Cylinder): 1404kg
- Panel Van (6 Cylinder): 1432kg
- Panel Van (8 Cylinder): 1476kg
- One-Tonner (6 Cylinder): 1292kg
- One-Tonner (8 Cylinder): 1336kg
- Statesman Caprice: 1719kg
- Statesman DeVille: 1681kg
- Turning Circle:
- Fuel Tank Capacity:
- Commercials: 70.4 litres
- Statesmans: 91 litres (optional 126
litres)
- Instruments:
- Statesman:
- Speedometer with integrated
odometer and trip meter
- Petrol gauge
- Oil pressure gauge
- Temperature gauge
- Voltmeter
- Digital Clock (Caprice)
- Analogue Clock (DeVille)
- Tachometer (Caprice)
- Warning lamp cluster including
warning lamps for brake system failure,
hand brake, high beam, turning signal,
taillamp failure, door adjar, low
fuel, seat belt
- 3.3 202 Engine (Commercials):
- Capacity: 201.25 cubic inches (3.298
litres)
- Type: Conventional, watercooled four
stroke, reciprocating piston type with
6 cylinders
- Configuration: Front mounted, longitudinal,
inline
- Head: Pushrod and rocker actuated
ohv with two valves per cylinder
- Fuel System: GM Strasbourg Varajet twin barrel downdraft carburettor
- Bore and Stroke: 92.1 x 82.5mm
- Power:
- Manual Transmission: 83kw at
4000rpm
- Torque: 231Nm at 2400rpm
- Compression Ratio: 8.8:1
- 253 4.2 Litre V8 Engine (Commercials):
- Capacity: 252.8 cubic inches (4.142
litres)
- Type: Conventional, watercooled four
stroke, reciprocating piston type with
8 cylinders
- Configuration: Front mounted, longitudinal,
Vee configuration
- Head: Pushrod and rocker actuated
ohv with two valves per cylinder
- Fuel System: Rochester Quadrajet four barrel downdraft carburettor
- Bore and Stroke: 92.1 x 77.8mm
- Power
- Single exhaust : 100kw at 4200rpm
- Dual Exhaust: 115kw at 4400rpm
- Torque
- Single exhaust : 269Nm at 2000rpm
- Dual Exhaust: 289Nm at 3200rpm
- Compression Ratio: 9:1
|
- 308 5.0 Litre V8 Engine (Statesman
DeVille & Caprice):
- Capacity: 307.8 cubic inches (5.044
litres)
- Type: Conventional, watercooled four
stroke, reciprocating piston type with
8 cylinders
- Configuration: Front mounted, longitudinal,
Vee configuration
- Head: Pushrod and rocker actuated
ohv with two valves per cylinder
- Fuel System: Rochester
Quadrajet 4BBL downdraft carburettor
- Bore and Stroke: 101.6 x 77.8mm
- Power: 126kw at 4400rpm
- Torque: 361Nm at 2800rpm
- Compression Ratio: 9.2:1
- 308 5.0 Litre V8 Engine (HDT Statesman
Magnum):
- Capacity: 307.8 cubic inches (5.044
litres)
- Type: Conventional, watercooled four
stroke, reciprocating piston type with
8 cylinders
- Configuration: Front mounted, longitudinal,
Vee configuration
- Head: Pushrod and rocker actuated ohv
with two valves per cylinder
- Fuel System: Four Barrel
downdraft carburettor
- Bore and Stroke: 101.6 x 77.8mm
- Power: 188.2kw at 5000rpm
- Torque: 428.8Nm at 3500rpm
- Compression Ratio: 9.2:1
- Ignition and Electrical:
- Commercials:
- 12 volt with 40 amp alternator
(55 amp if air-conditioning fitted)
- Pre-engaged drive starter motor
- High energy breakerless ignition
with 8mm silicone rubber insulated
fibreglass core ignition leads
- Statesmans:
- 12 volt with 55 amp alternator
- 62 amp battery
- Pre-engaged drive starter motor
- High energy breakerless ignition
with 8mm silicone rubber insulated
fibreglass core ignition leads
- Exhaust:
- Commericals:
- 6 Cylinder: manifold seperating
first 3 from last 3 cylinders,
entering into twin outlet flange
with dual exhaust pipes leading
into a single pipe, muffler and
tail pi4pe
- 8 Cylinder: separate front exhaust pipes from each side of the engine,
with a cross-over into a single
rear pipe to the muffler, and a
single rear tail pipe
- Statesman:
- Seperate pipe and resonator assemblies
from each side of the engine leading
into dual mufflers. Each muffler
in turn with intermediate pipe
to single muffler at rear left
hand side of car
- HDT Statesman Magnum:
- Transmission Options:
- 3-speed (M15)
- 4-speed (M20, M21, M22)
- Tri-matic (M40), Turbo 350 (M38)
- Note: Turbo boxes
were deleted around august 1982 and replaced
with Tri-matics (308 only).
- Utility and Panel Van - 3 speed
Manual Transmission (3.3 six and 4.2
V8):
- 1st: 3.07:1
- 2nd: 1.68:1
- 3rd: 1.00:1
- Reverse: 3.59:1
- Utility and Panel Van - Optional
4 speed Manual Transmission (3.3 six and
4.2 V8):
- 1st: 3.05:1
- 2nd: 2.19:1
- 3rd: 1.51:1
- 4th: 1.00:1
- Reverse: 3.05:1
- Utility and Panel Van - Optional Tri-Matic
Automatic Transmission:
- 1st: 2.31:1
- 2nd: 1.46:1
- 3rd: 1.00:1
- Reverse: 1.85:1
- Statesmans - Turbo-Hydramatic
400 Automatic:
- 1st: 2.48:1
- 2nd: 1.48:1
- 3rd: 1.00:1
- Reverse: 2.08:1
- Clutch:
- GMH diaphragm single dry plate
- Belleville diaphragm
- Rear Axle Ratio:
- Commercials (excluding One Tonner):
3.55:1
- One-Tonner:
4.44:1 (optioanl 3.36:1)
- Statesman: 3.08:1
- Statesman towing/performance option:
3.36:1
- Statesman Series II: 2.60:1
- Top Speed in Gears:
- Statesman DeVille (126kw version):
- 1st: 70 km/h
- 2nd: 140 km/h
- 3rd: 175 km/h
- 0-100 km/h: 9.7 seconds
- Standing Quarter Mile (400 metres):
17.0 seconds
- Kingswood 253 4.2 litre V8 Utility
manual:
- 1st: 65 km/h
- 2nd: 90 km/h
- 3rd: 130 km/h
- 4th: 170 km/h
- 0-100 km/h: 12.2 seconds
- Standing Quarter Mile (400 metres):
17.8 seconds
- Statesman Caprice:
- 1st: 72 km/h
- 2nd: 122 km/h
- 3rd: 180 km/h
- 0-100 km/h: 11.8 seconds
- Standing Quarter Mile (400 metres):
18 seconds
- Statesman DeVille:
- 1st: 48 mph (78 km/h)
- 2nd: 82 mph (132 km/h)
- 3rd: 103 mph (165 km/h)
- 0-100 km/h: 10.9 seconds
- Standing Quarter Mile (400 metres):
18.6 seconds
- HDT Holden Statesman Magnum:
- 1st: 111 km/h
- 2nd: 175 km/h
- 3rd: 200 km/h
- 0-100 km/h: 9.43 seconds
- Standing Quarter Mile (400 metres):
16.76 seconds
- Suspension:
- Commercials:
- Front: Independent, coil sprints
- Rear: Independent, coil sprints
- Statesman:
- Front: Independent with short and
long arms, coil springs, decoupled
stabiuliser bar
- Rear: Four-link system with coil
springs, decoupled stabiliser bar
- Steering:
- Commercials:
- Standard: Front-mounted recirculating
ball type. Standard ratio 25:1
- Optional power assisted: Integral
variable ratio gear with rotary type
control valve and hydraulic pump.
Ratio varies from 18:1 to 11.7:1
- Statesman:
- Integral variable power steering,
ratio 18.1:1
- Brakes:
- Commercials:
- Front: Power assisted
discs standard
- Rear: Drums, duo-servo
- Statesman:
- Front: Power assisted 276mm ventilated
discs
- Rear: Power assisted 293mm solid
discs
- Wheels:
- Commercials:
- Statesman:
- DeVille: Steel with full wheel
cover, 6.00JJ x 14 standard
- Caprice: Styled cast alloy, 7.00JJ
x 15 standard
- HDT Magnum: Momo alloy,
7.00JJ x 15 standard
- Tyres:
- Commercials:
- Utility and Panel Van: FR78S14
x 4 steel belted radials
- One-Tonner: 195R14LT x 8 steel
belted radials
- Statesman:
- DeVille: FR 78 H15
- Caprice: ER 60 H15
- HDT Magnum: Pirelli P6 235/30 VR
15
